Electric Air Heater Manufacturer
Specified and manufactured to your requirements
Typically -
- 1.5mm Galvanised steel construction
- IP30 Terminal box
- Manual reset high temperature safety cut-
out - Terminations ready for wiring to your controls
Alternative Options
- 1.5mm Stainless steel construction
- IP54 Terminal box
- Auto reset high temperature safety cut-
out
High Air Temperature Electric Heaters
|
|
A |
B |
C |
Loading |
Air Vel |
Air Temp |
|
Min |
200mm |
250mm |
200mm |
0.25kW |
0.5m/s |
80°C |
|
Max |
2200mm |
2000mm |
1000mm |
1200kW |
12m/s |
400°C |
B
A
C
B
A
C
|
|
A |
B |
C |
Loading |
Air Vel |
Air Temp |
|
Min |
200mm |
250mm |
200mm |
0.25kW |
0.5m/s |
80°C |
|
Max |
2450mm |
2450mm |
1000mm |
1200kW |
12m/s |
400°C |
- Designed for process oven applications where higher air temperatures are required
- ‘Stand off’ terminal box to minimise heat transfer
- Can be either Plate Mounted or Flange Mounted
- Mounting plate can be insulated to match duct insulation
- Element support designed to allow for element expansion
- Supplied with high temperature safety cut-
out and terminations ready for wiring to your controls
